Horizontal Friction Washer Plastic Friction Machine Recycling Washing Equipment
Function:
The RAYFON EST horizontal friction washer is a core equipment for plastic recycling and cleaning, designed to remove impurities, oil stains, dust, labels, and adhesive residues from waste plastic materials through high-intensity mechanical friction, shearing, and water washing. It utilizes the relative motion between the rotating friction plate (or rotor) and the fixed cylinder to generate strong friction force, combined with continuous water flushing, achieving deep cleaning of plastic particles, flakes, or film fragments. The cleaned materials are separated from wastewater and impurities via a built-in screening or dehydration structure, ensuring the purity and quality of recycled plastics for subsequent processing (e.g., granulation, molding).
Key Features:
1.Efficient Cleaning Performance: Adopts a horizontal structure with optimized rotor design, generating uniform and intense friction to achieve ≥99% impurity removal rate, effectively eliminating stubborn contaminants like oil and adhesive.
2.Wide Material Adaptability: Suitable for cleaning various waste plastics, including PET bottle flakes, HDPE/PP film, PP/PS food containers, ABS plastic fragments, and other rigid/flexible plastic materials.
3.Energy & Water Saving: Equipped with a closed-loop water circulation system, reducing water consumption by 60% compared to traditional washers; low-power motor with frequency conversion control minimizes energy loss.
4.Durable & Wear-Resistant: Cylinder and rotor are made of high-strength stainless steel or wear-resistant alloy, with a service life 3x longer than ordinary materials; detachable friction plates for easy maintenance and replacement.
5.Automated Operation: Integrates with PLC control system, supporting automatic feeding, water level adjustment, and discharge; equipped with overload protection and fault alarm functions for safe and continuous production.
6.Compact Structure: Horizontal layout saves floor space, easy to integrate into existing plastic recycling lines.
Equipment Specification:
| ITEM | UNIT | RTSW-5012D | RTSW-6012D | RTSW-8015D |
| Rotor diameter | mm | 500 | 600 | 800 |
| Rotor width | mm | 1200 | 1200 | 1500 |
| Motor power | kW/HP | 22/30 | 30/40 | 55/75 |
| Machine Length | mm | 2230 | 2530 | 2750 |
| Machine Width | mm | 1630 | 1990 | 2230 |
| Machine Height | mm | 3450 | 3600 | 3700 |
| Dehydrating Rate | % | 98.5% | 98.5% | 98.5% |
| Process Capacity | KG/H | ≤1000 | ≤3000 | ≤5000 |
Physical Pictures:
Applications:
Plastic Recycling Industry: such as PET beverage bottles, HDPE/PP plastic bags, agricultural film, plastic buckets, and food packaging.
Recycled Plastic Granulation
Waste Treatment & Resource Utilization
Plastic Product Processing
HDPE daily household waste containers
PP plastic busket, beverage cup
ABS PS Toy car
